Traefik Reverse Proxy: Complete Homelab Guide

The Gateway to Your Homelab

A reverse proxy is essential for any serious homelab. It routes traffic to different services based on domain names, handles SSL certificates, and provides a single entry point to your infrastructure.

Traefik is a modern reverse proxy designed for containerized environments. It automatically discovers services and configures routing through Docker labels.

Why Traefik?

• Automatic discovery: Detects new containers and configures routing
• Docker native: Configuration through container labels
• Automatic SSL: Let's Encrypt integration built-in
• Dashboard: Real-time view of routes and services
• Middleware: Authentication, rate limiting, headers

Basic Setup

# docker-compose.yml
services:
  traefik:
    image: traefik:v3.0
    container_name: traefik
    command:
      - "--api.dashboard=true"
      - "--providers.docker=true"
      - "--providers.docker.exposedbydefault=false"
      - "--entrypoints.web.address=:80"
      - "--entrypoints.websecure.address=:443"
      - "--entrypoints.web.http.redirections.entrypoint.to=websecure"
      - "[email protected]"
      - "--certificatesresolvers.letsencrypt.acme.storage=/letsencrypt/acme.json"
      - "--certificatesresolvers.letsencrypt.acme.httpchallenge.entrypoint=web"
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./letsencrypt:/letsencrypt
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.dashboard.rule=Host(`traefik.yourdomain.com`)"
      - "traefik.http.routers.dashboard.service=api@internal"
      - "traefik.http.routers.dashboard.tls.certresolver=letsencrypt"
    restart: unless-stopped
    networks:
      - traefik

networks:
  traefik:
    external: true

Create the network first: docker network create traefik

Adding Services

Add labels to any service to expose it through Traefik:

services:
  nextcloud:
    image: nextcloud:latest
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.nextcloud.rule=Host(`cloud.yourdomain.com`)"
      - "traefik.http.routers.nextcloud.entrypoints=websecure"
      - "traefik.http.routers.nextcloud.tls.certresolver=letsencrypt"
      - "traefik.http.services.nextcloud.loadbalancer.server.port=80"
    networks:
      - traefik

networks:
  traefik:
    external: true

Authentication Middleware

Add basic authentication to any service:

# Generate password: htpasswd -nb admin password
# Result: admin:$apr1$xyz...

labels:
  - "traefik.http.middlewares.auth.basicauth.users=admin:$$apr1$$xyz..."
  - "traefik.http.routers.myservice.middlewares=auth"

Common Middlewares

# Redirect HTTP to HTTPS
- "traefik.http.middlewares.https-redirect.redirectscheme.scheme=https"

# Security headers
- "traefik.http.middlewares.security.headers.stsSeconds=31536000"
- "traefik.http.middlewares.security.headers.browserXssFilter=true"

# Rate limiting
- "traefik.http.middlewares.ratelimit.ratelimit.average=100"

# IP whitelist
- "traefik.http.middlewares.local.ipwhitelist.sourcerange=192.168.1.0/24"

Your Traffic Controller

Once Traefik is running, adding new services is as simple as adding labels. No more editing nginx configurations or restarting proxies - Traefik handles it all automatically.
